Equipment | HT 2000

The HT indicates that the drill rig is of a modular design and can be made helicopter transportable. The versatility of this rig is unparalleled. It has been utilized for multiple specialised projects ranging from deep PQ permafrost coring in the High Arctic, horizontal and directional holes to 1,000 feet, large diameter water wells, and reverse circulation drilling. It can be configured for 12” reverse flood Bulk Diamond sampling.

The HT-2000 series drills were specifically designed and manufactured for use by Foundex, in order to meet our requirements for specialized projects. These drills are extremely versatile and their modular design also permits the machine to be easily switched and mounted on skids, truck or tracked carriers.

We carry an extensive inventory of specialty tooling and equipment to support all operations of the HT 2000 and to meet all of your project requirements.


Equipment Brief

  • Mud or Air Rotary

  • Odex and Down Hole Hammer Drilling

  • Vertical, Incline, Horizontal and Directional Drilling


Specifications

  • 165 HP Air Cooled Diesel Engine

  • Head Torque - 0 to 12,000 ft/lbs

  • Head RPM - 0 to 150

  • Head Travel - 12 feet

  • Pull Down Pressure - 30,000 lbs

  • Pullback Pressure - 38,000 lbs

  • Main Winch - 12,000 lbs

  • Secondary Winch - 5,000 lbs

  • Wireline Winch - 1,500 lbs


Rig Capacity

  • 12” Mud Rotary to 1,000 feet

  • 12” Casing Systems to 250 feet

  • Hole Diameters 2” to 16”

Capacities are contingent on ground conditions












​

  • Mast Length - 18 feet

  • Hydraulic Rod Clamp - 2” to 14”

  • Hydraulic Breakout Wrench 2” to 14”

  • Head Off Holes for Free Rod Tripping - 15 foot

  • Gardner Denver Duplex Mud Pumps - 200 gpm at 450 psi

  • W1122 FMC Bean Triplex Pumps - 30 gpm at 1000 psi
